Pepperl + Fuchs Inductive Threaded Barrel Proximity Sensor, M18, 5 mm Detection, NPN NO, 5 → 36 V dc

RS Stock No.: 249-2372Brand: Pepperl + FuchsManufacturers Part No.: NBB5-18GM50-E0-V1
brand-logo
View all in Proximity Sensors

Technical documents

Specifications

Brand

Pepperl + Fuchs

Thread Size

M18

Sensor Technology

Inductive

Detection Range

5 mm

Body Style

Threaded Barrel

Output Function

NO

Digital Switching Output Type

NPN

Connection Type

M12

Supply Voltage

5 → 36 V dc

Length

65mm

IP Rating

IP68

Mounting Type

Flush

Housing Material

Brass, White Bronze Coated

Maximum dc Voltage

36V

Minimum Operating Temperature

-40°C

Short Circuit Overload Protection

Yes

Depth

18mm

Maximum Operating Temperature

+85°C

Shielding

Shielded

Maximum Switching Frequency

1.95kHz

Switching Current

200 mA

Reverse Polarity Protection

Yes

Switching Frequency

1.95 kHz
