Omron PCB Mount Non-Latching Relay, 12V dc Coil, 5A Switching Current, DPDT
Technical documents
Specifications
Brand
OmronCoil Voltage
12V dc
Contact Configuration
DPDT
Mounting Type
PCB Mount
Switching Current
5A
Number of Poles
2
Terminal Type
Plug In
Length
29mm
Coil Resistance
278 Ω
Series
G2R
Depth
13mm
Height
41.7mm
Standards Met
CE
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+70°C
Maximum Switching Power DC
150 W
Maximum Switching Power AC
1.25 kVA
Maximum Switching Power (AC)
1.25 kVA
Application
General Purpose
Country of Origin
Malaysia
Product details
G2RS Series with Test Button & Back E.M.F Suppression Diode
Integral coil status LED, and mechanical operation indicator
Cadmium and lead free
Contact resistance: 100mΩ
Coil to contact isolation: 5000Vac
Operating temperature range: -40 to + 70°C
H35.5, W29, D13mm
DIN Rail and PCB sockets are available separately
Approvals
UL, CSA, VDE
